Engine Specifications

• Vanguard, model 380000, air cooled engine
• V-Twin cylinder, 4-stroke gasoline engine
• Electric start with recoil start as backup
• 2.25 Gallons (8.5 L) integrated fuel tank

Included Accessories

• Full control panel with pressure gauge, vacuum gauge, throttle, choke, starter, panel light and priming valve
• 16 Amps alternator
• Low oil alert
• 12-V battery

Pump Unit Specifications

• C.E.T. single stage centrifugal pump
• Pump body made from high resistance aluminum alloy
• Bronze impeller
• Mechanical shaft seal
• Exhaust priming system, guaranteed up to 20' (6 meter) lift
• One 2 1/2" (65 mm) delivery outlets with Fire Type swing-out valve
• One 4" (100 mm) suction inlet
• Dimensions: 24 3/4" Length by 26 1/4" Width by 25 3/4" Height
• Weight: 188 lbs
