Pittman Center VFD (TN)

Call now (800) 628-6233 (x155) or email apparatussales@nafeco.com for more information.

Type	Pumper
Body	3/16” Formed Aluminum FX Body Hosebed Storage for 600’ of 2.5” Double Jacket Hose; 1200’ of 3” Double Jacket Hose 26” Deep Compartments Internal Ladder Storage Hydraulic Folding Tank Storage Rack Rear Access Ladder Wheel Well Storage for Four (4) SCBA Bottles
Chassis	Freightliner M2 112 49,080# GVWR Frame Rails with Liner Aluminum Wheels Electronic Stability Control 16” Front Bumper Extension with Hose Well Compartment Aluminum Treadplate Cab Step Overlays
Dimensions	Overall Height: 120” Overall Length: 381” Wheelbase: 224”
Drive Train	Cummins L9 Diesel Engine 450 HP Allison 3000 EVS Automatic Transmission
Electrical	Battery Charger System with Air Compressor and Auto Eject Fire Tech 46” LED Brow Light with Integrated Marker Lights Rear Camera System Two (2) Streamlight Portable Handlights Whelen LED Warning Light Package Fire Tech Guardian LED Scene Light Package Federal Q2B Siren, Partially Recessed
Pump and Tank	Rosenbauer N Midship Pump PTO Pump Shift with Pump and Roll Capabilities 1500 GPM Trident Automatic Primer Akron Foam Eductor 2000 Gallons Poly Water Tank 20 Gallon Foam Tank Remote Water Level Gauges—Body Sides and Rear Body Panel Fireman’s Friend Direct Tank Fill 10” Rear Dump with Swivel Dump Chute
Schematic Drawing
