Engine Specifications

• D722 Kubota liquid cooled engine
• 3-cylinder, 4-stroke diesel engine
• 12V electric start
• Alternator capacity: 12V- 12.5A (150W)

Included Accessories and Control Panel

• 12-V battery
• Engine ignition switch
• Throttle control vernier
• Operating panel light
• Pilot lights
• Inlet and outlet pressure gauges
• Priming valve
• Engine stop knob

Pump Unit Specifications

• C.E.T. single stage centrifugal pump
• Pump body made from salt water resistant aluminum alloy
• Bronze impeller
• Mechanical shaft seal
• Stainless steel pump shaft
• Exhaust priming system, guaranteed up to 15' (4.6 meter) lift
• One 1 1/2" (38 mm) delivery outlet with Fire Type swing-out valve
• One 2 1/2" (65 mm) suction inlet
• Dimensions: 32" Length by 27" Width by 33" Height
• Weight: 325 lbs
