Engine Specifications

• Yanmar, model L100, air cooled engine
• Single cylinder, 4-stroke diesel engine
• 12V electric start with recoil start as backup
• 1.45 gallon (5.5 l) integrated fuel tank

Included Accessories

• Swivel spotlight
• 100 watts alternatore
• Pressure gauge
• Vernier throttle
• 12-V battery

Pump Unit Specifications

• Direct drive C.E.T. single stage centrifugal pump
• Pump body made from resistant aluminum alloy
• Bronze impeller
• Mechanical shaft seal
• Stainless steel pump shaft
• Exhuast priming system, guaranteed up to 20' (6 meter lift)
• One 2 1/2" (65 mm) delivery outlet with 1/4 turn ball valve
• One 3" (77 mm) suction inlet
• Dimensions: 25 1/2 Length by 20 1/2" Width by 23 3/4" Height
• Weight: 195.8 lbs
