Pine Grove Volunteer Fire Department (AL)

Call now (800) 628-6233 (x155) or email NAFECO Apparatus Sales for more information.

Type	Tanker
Body	Rosenbauer FX, 3/16” Aluminum, 240” long x 98” wide 16” Front Bumper Extension with Left and Right Hose Well Compartments Running Board Hose Wells Electric Rear Dump Valve with Electric Tandem Dump Valves Dump Valve Controls on Rear Body Panel and In Cab Through the Tank Ladder Storage Suction Hose Storage over Tank Rack Inverter/Charger/Compressor System “Blacked Out” Finish
Chassis	Rosenbauer Commander 3311, 2 Door Cab 33” Cab with 11” Raised Roof Cab Compartments with Slide Out Tool Boards Full Length Cab Doors Cab Seating for Two (2)
Dimensions	Overall Height: 119” Overall Length: 441” Wheelbase: 227” 67,000 lb. GVWR
Drive Train	Cummins L9, 450 HP Allison 3000 EVS
Electrical	Electronic Stability Control Weldon VMux Electrical System Fire Tech 72” LED Brow Light Triple Camera System Whelen LED Warning Light Package Fire Tech LED Scene Light Package Wig-Wag Headlight Flashers Federal Q2B Siren Electric Folding Tank Rack
Pump and Tank	3000 Gallon “T” Water Tank Hale RSD, 1250 GPM, Single Stage, Midship PTO Rear Direct Tank Fill
Schematic Drawing
